Back cover for wire arrangement, 50py3d/f, 60py3d/f, Preparation – LG 32LB9D User Manual
Page 16
PREP
AR
A
TION
14
PREPARATION
Hold the CABLE MANAGEMENT with both hands and pull it as shown.
Connect the cables as necessary.
To connect an additional equipment, see the External equipment Connections section.
1
2
Install the CABLE MANAGEMENT as shown.
3
CABLE MANAGEMENT
50PY3D/F, 60PY3D/F
45°
BACK COVER FOR WIRE ARRANGEMENT
■
Here shown may be somewhat different from your TV.
