1. Slide handle onto the main body.

Attaching handle

Attaching the Hose

2. Insert screw into the back side of the handle

and tighten using a Phillips head screwdriver.

1. Insert the wand into the handle hose.

2. Attach the opposite side of the hose onto

the main body.

3. Align the hose with the holder on the side

of the vacuum and place the end of the

wand onto the main body.

Button

Hole

Tighten screw as much as you can.

Personal injury or product damage

can occur.

WARNING

ASSEMBLY

8
