Replacing the Agitator Belt
If the belt breaks, follow the steps below to replace
the agitator belt.
To Replace the Belt:
1. Remove the agitator brush cover as described
on page 18.
2. Lift the agitator straight out.
3. Unhook the old belt from the drive pulley.
Make sure no pieces of the broken belt are
trapped in the agitator or drive pulley area.
4. Hook the new belt over drive pulley of agitator
motor.
5. Fit the agitator through the belt, making sure
the belt is aligned with the pulley section of the
agitator.
6. Lower the agitator into place, making sure the
oval shaped tabs fit into the indents on the head.
7. Reinstall the agitator brush cover as described
above.
For a replacement belt, order LG service center
belt part # MAS61843401.
Electrical shock and personal injury hazard.
Always unplug the vacuum cleaner before
servicing. Failure to do so could result in
electrical shock or personal injury.
WARNING
