Installation

Mounting the
speakers to a wall

You can mount the speakers to a wall. Prepare
screws and brackets supplied.

1. Attach the wall bracket to the wall with

screws as shown in the illustration below.

When you mount to a wall(concrete), use
the wall plugs. You should drill some holes
(Diameter: 6 mm, Depth: more than 32 mm)
for the mounting.

Screw & Wall plug

20 mm

32 mm

3.5 mm

6 mm

Step 1

Wall plug

Screw

Wall plug

2. Attach the speaker bracket to the speaker

and fasten the screws.

Step 2

3. Hang the speaker bracket onto the wall

bracket.

Step 3

4. Press the speaker to secure the brackets.

Step 4
