15 Preparation
2
Pr
eparation
a AC Power cord
Plug into the power source.
b Speakers connectors
c Cooling Fan
d Antenna Connector
e VIDEO OUT
f Wireless transmitter
g AUX (L/R) INPUT
h COMPONENT VIDEO (Y P
B
P
R
)
OUTPUT (PROGRESSIVE SCAN)
i OPTICAL IN 1(TV) / 2
j HDMI IN (type A, Version 1.3) 1/2
k HDMI OUT (type A, Version 1.3)
Connect to TV with HDMI inputs.
l LAN port
Rear panel
