Cable Service with VCR Hookup
P A G E 1 2
Locate the Antenna/Cable jack on the
back of the VCR.
Connect the cable service wire to the VCR.
Connect other wires according to the
diagram to the right.
After all connections are complete, plug
in the TV. The LCD TV/Monitor is designed
to operate on AC power.
1
2
3
Connect cable service and a VCR to the LCD TV/Monitor.
For cable box operation, leave the VCR
and the television tuned to channel
three or four and use the cable box to
change channels.
RS-232C
SPEAKER SWITCH
PILLOW
SPEAKER NORMAL
SPEAKER FUTURE
USE UPDATE
VIDEO
AUDIO IN VIDEO IN
RS-232C
SELECT
CONTROL NORMAL
(DTV)
Cable Box
Cable TV
Wall Jack
Cable TV
Wall Jack
Connections Panel
VCR AV Panel
