Page 11
Antenna & VCR Hookup
P A G E 1 1
Locate the Antenna/Cable jack on
the back of the VCR.
Connect the antenna wire that runs
from the wall jack to the VCR.
Connect other wires according to
the diagram to the right.
After all connections are complete,
plug in the TV. The LCD TV/Monitor
is designed to operate on AC power.
1
2
3
Connect antenna and a VCR to the LCD TV/Monitor.
RS-232C
SPEAKER SWITCH
PILLOW
SPEAKER
NORMAL
SPEAKER
FUTURE
USE
UPDATE
VIDEO
AUDIO IN
VIDEO IN
RS-232C
SELECT
CONTROL
NORMAL
(DTV)
300/75ohm
Adapter
VCR Back Panel
Round
or
Flat wire
(300 ohm)
Connections Panel
