Page 8
7
Connecting the Display
Height Range : maximum 3.93 inches (100.0 mm)
* Please be sure to
remove the Locking
pin to adjust the height.
100.0 mm
Positioning your display
After installation, adjust the angle as shown below.
1.
Adjust the position of the panel in various ways for maximum comfort.
Tilt Range
Swivel Range : 355˚
