BreezeNET DS.11 Series User Manual
6-2
Radio
Frequency Range 2.4 - 2.4835 GHz
Radio Type Direct Sequence Spread Spectrum (DSSS)
Wireless LAN Standards Compliant with IEEE 802.11b HR
Selectable sub Channels
FCC : 1-11
ETSI : 1-13
Japan TELEC : 1-13
France : 10-13
Output Power
(at the antenna port)
FCC: -4, -2, 4, 6, 12, 14, 20, 24 (dBm)
ETSI -4, -2, 4, 6, 12, 14 (dBm)
Japan TELEC -4, -2, 4, 6, 12, 14 (dBm)
Data Rate Sensitivity Modulation
11 Mbit/s -85 dBm 256 CCK
5.5 Mbit/s -88 dBm 16 CCK
2 Mbit/s -90 dBm DQPSK
Sensitivity
(BER 10E-6)
1 Mbit/s -93 dBm DBPSK
Processing Gain
10.4 dB Nominal
Integrated Antenna Type Flat Panel 16 dBi, 20 ° Vertical /Horizontal
Range
Europe/ ETSI
(20 dBm EIRP) Up to 10 km
US FCC Up to 25 km (15 miles)
Security
Authentication and Data
Encryption 64 bit and 128 bit RC4 WEP
Scrambling Proprietary
