AA-PPRC
4.0 SPECIFICATIONS
Type Speaker Line Remote Switcher
Channels 2
Circuit Design Relay Switching
Load Rating Watts 350 W @ 70V (See Load Chart for other Load Ratings)
Load Rating Amps 5 Amps. per channel MAX
Indicators
One Bi-color LED Red/Green
Inputs Qty. 4 Four Position Detachable Phoenix Connectors
Maximum Input Level 100V AC
Outputs Qty. 1 Four Position Detachable Phoenix Connector
Maximum Output Level 100V AC
Trigger Inputs DC Trigger 3V-24V DC Auto Sense
External Switch Trigger – Contact Closure
Line Level Trigger Input – Min 10mV, Max 5V
Speaker Level Trigger Input – Min 3V, Max 100V
Threshold Adjustments Line Level Trigger Threshold – 10mV - 3V AC
Speaker Level Trigger Threshold – 3V - 45V AC
Trigger Delay Adjustment – 500 ms - 30 sec
Frequency Response 20 Hz – 20 kHz Flat
Enclosure Metal
Finish Powder Coat Black with White Lettering
Mounting Screw hole tabs
Power Requirement 115/230V 50/60 Hz External UL Rated 12V DC Supply
Power Consumption 10 mA, .3 W
Dimensions (H x W x D) 1.5” (3.81 cm) x 4” (10.16 cm) x 4.5” (11.43 cm)
Weight Unit 1 lbs (.45 kg) Shipping 2 lbs (.9 kg)
