PREP
AR
A
TION
20
PREPARATION
ANTENNA ANTENNA IN M.P M.P.I.
M.P. I.
Card Slot
R R FF C C A A B B LL E E
RF cable needs to be dis-
connected to remove cur-
rent card.
1. Remove the two MPI card retainer screws.
2. Pull out current MPI card far enough so that the RF cable can be detached from the old card.
2. Detach RF cable.
3. Place new PPV card into slot and slide it in far enough to reconnect RF cable.
4. Reconnect RF cable.
5. Insert card all the way into the slot making sure it is fully seated into back plane connector.
6. Replace the two card retainer screws.
The MPI card is equipped with an RF jack for antenna/cable signal source connection.
The slot is also available for installing a PPV (Pay-Per-View) card.
MPI Card Removal / PPV Card Installation
MPI CARD SLOT
