EXTERNAL EQUIPMENT SETUP
HD RECEIVER SETUP
This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do
receive digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.
MI IN
/DVI IN
AUDIO
(RGB/DVI)
RGB(PC) R
CON
R
(CONT
( ) S- ( )
COMPONENT IN
1
2
VIDEO AUDIO
Y L R P B P R
( )
SERVICE
When connecting Component cable
1 2
1. How to connect
Connect the video outputs (Y, P B , P R
) of the digital set
top box to the C CO OM MPPO ON NEEN NTT IIN N VVIID DEEO O 1 1 jacks on
the set. Match the jack colors (Y = green, P B = blue, and
P R = red).
Connect the audio output of the digital set-top box to
the C
CO OM MPPO ON NEEN NTT IIN N AAU UD DIIO O 1 1 jacks on the set.
2
1
2. How to use
■ Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box. operation)
■ Select C Coom mppoonneenntt 1 1 input source by using the IIN NPPU UTT
button on the remote control.
■ If connected to C CO OM MPPO ON NEEN NTT IIN N2 2 input, select
C Coom mppoonneenntt 2 2 input source.
■ To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.
■ This part of EXTERNAL EQUIPMENT SETUP mainly use picture for LCD TV model.
Signal
480i
480p
720p
1080i
1080p
Component 1/2
Yes
Yes
Yes
Yes
Yes
HDMI1/DVI,
HDMI2
No
Yes
Yes
Yes
Yes
Y, C B/ P B , C R/ P R
Horizontal Vertical
Frequency(KHz) Frequency(Hz)
15.73 59.94
15.73 60.00
31.47 59.94
31.50 60.00
44.96 59.94
45.00 60.00
33.72 59.94
33.75 60.00
26.97 23.976
27.00 24.00
33.71 29.97
33.75 30.00
67.432 59.94
67.50 60.00
Resolution
720x480i
720x480p
1280x720p
1920x1080i
1920x1080p
