PREP
AR
ATION
15
STAND INSTALLATION
(Only 32LC7D/7DC, 37LC7D)
Carefully place the product screen side down on
a cushioned surface that will protect product and
screen from damage.
Assemble the product stand with the product as
shown.
Securely install the 4 bolts provided.
1
2
3
VESA WALL MOUNTING
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
G G Screw length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE !
R
( )
R
( )
Plasma TV Model LCD TV Model
600 mm
400 mm 400 mm
(32LC7D/7DC only: 100 mm)
600 mm
(32LC7D/7DC only: 200 mm)
