Descriptions
• ISO/IEC 8802-3; ANSI/IEEE standard 802.3 part 3
- IEEE 802.3x – Full Duplex capable
- IEEE 802.3u – Auto negotiation
• RFC 1213 S K. McCloghrie, M. Rose, "Management
Information Base for Network management of
TCP/IP-based internet: MIB-II", 03/26/1991
• D-I-X, "The Ethernet - A Local Area Network:
Data Link Layer and Physical Layer Specifications",
Digital, Intel, and Xerox, November 1982.
• IEEE 802.11B
• IEEE 802.11G
• WEP 64 and 128 bit encryption
• 802.1x
• Transparent MAC level bridge for Ethernet-like
devices in conformance with the IEEE802.1d
specification.
• ISO/IEC 10038:1993 (E), Std 802.1D.
• RFC1213 S K. McCloghrie, M. Rose, "Management
Information Base for Network Management of
TCP/IP-based internet: MIB-II", 03/26/1991.
• RFC1493 Definitions of Managed Objects for
Bridges. E. Decker, P. Langille, A. Rijsinghani, & K.
McCloghrie. July 1993.
• RFC 2131: Dynamic Host Configuration Protocol:
R. Droms, March 1997.
• RFC 2132: DHCP Options and BOOTP Vendor
Extensions: S. Alexander, March 1997.
• The DHCP client supports the following minimal
subset of options described in RFC2132:
- Requested IP Address (requested by default; is
mandatory)
- Parameter Request list (subnet-mask only)
- IP Address Lease time (dhcp-lease-time)
- Client-identifier (dhcp-client-identifier)
- Default route (routers)
- DNS servers
• RFC 1350, The TFTP Protocol (Revision 2).
K. Sollins. July 1992.
• FTP server is in boot loader only.
• RFC 1945, Hypertext Transfer Protocol --
HTTP/1.0. T. Berners-Lee, R. Fielding, H. Frystyk.
May 1996.
Features
Ethernet
Wireless
Wireless Security
Bridge
DHCP Client
FTP Server/Client
Web server and Web
Based
Configuration
• RFC 2068, Hypertext Transfer Protocol --HTTP/1.1. R.
Fielding, J. Gettys, J. Mogul, H. Frystyk, T. Berners-Lee.
January 1997. (Not full support).
• RFC 2617, HTTP Authentication: Basic and Digest Access
Authentication. J. Franks, P. Hallam-Baker, J. Hostetler, S.
Lawrence, P. Leach, A. Luotonen, L. Stewart. June 1999.
The enclosure has the following physical dimensions:
Length: 3 3/4 inch
Width: 3 1/4 inch
Height: 1 1/4 inch
Power: ON/OFF Ready indicator;
Solid Green
= Power on
Off = Power off
WLAN: WLAN indicator light that indicates
whether or not it has at least one session up.
Solid Light Green = LAN Cable
connection or WLAN
association to an
Access Point
Off = Modem power off or
WAN connection
not present.
Flickering Green = Wireless or LAN
port activity
(either direction)
RJ-45: One for Ethernet LAN connection
Power: One power connector for wall mount
12V DC power adapter
Reset Button: Reset the unit and Reset to manufacturing
default
Antenna: One detachable using an RP-SMA
connector
Operating temperature: 0-55 degrees Celsius
Humidity:
5-98%, non-condensing
Operating voltage: +5V DC +- 5% @ 2A max
Power Dissipation for GT701-EA
Active (typical)
5V DC @ 1.2A
Web server and Web
Based
Configuration
(continued)
Enclosure
Visual indicators
Connectors:
Environmental
Operating Range
Power Requirements
Power Dissipation
