Wireless Multi-Function Access Point
1.7 TCP/IP
The Wireless Multi-Function Access Point can be
configured with your Web browser. The web browser is
included as a standard application in the following operation
systems, UNIX, Linux, Mac OS, Windows
95/98/NT/2000/Me, and etc. The product provides a very
easy and user-friendly interface for configuration.
Port Meaning
Reverse
SMA
Connectors There are two antennas in the rear
panel, when you need to connect
extended Antenna, connect to
Antenna 2 for the extended antenna.
When you are using one antenna
model, connect the extended antenna
directly to the antenna screw in the
rear panel.
LAN
Ethernet uplink port with 10/100Mbps
Fast Ethernet connections, connect
this port to switch/hub.
Reset
The Reset function is to reset the
setting back to factory default setting,
once you press the “RESET” button
within 10 seconds, the LED of the
WLAN will turn off. And when the
Access Point is ready, the WLAN LED
will start blinking.
And the other function is when the AP
is locked, press the reset button to
unlock it.
POWER
(DC-IN)
Connect the Power Adapter DC plug
to the AP’s power jack.
