45 CDHF-SVU01C-EN
Operator
Interface
System Mode Overrides
Description
Resolution or (Enumerations), Default Units Monitor Value
1. Compressor XXX / (Auto,Manual [0-100] ), Auto Enum IGV % Open
Control Signal Evap. LWT
AFD Freq.
2. Evap Water Pump (Auto, On), Auto Enum 1) Evap Flow
status
2) Override Tim
e Remaining
3. Cond Water Pump (Auto, On), Auto Enum 1) Cond Flow
status
2) Override Time
Remaining
Circuit Mode Overrides
Description
Resolution or (Enumerations), Default Units Monitor Value
1. Oil Pump (Auto, On), Auto Enum 1) Diff press
2) Override Time
Remaining
2. Clear Restart Inhibit Timer
3. Purge Exhaust Circuit Test
(Off, On), Off Enum none
4. Purge Regen Cycle (Off, On), Off Enum Carbon Temp
5. Front Panel Ckt Lockout (Not Locked Out, Locked Out), Not Locked Out Enum
Purge
Description
Resolution or (Enumerations), Default Units
1. Purge Operating Mode (Auto, On, Adaptive, Stop), Adaptive Enum
2. Daily Pumpout Limit XXX Minutes
3. Disable Daily Pumpout Limit
(0 to disable)
0, XX Hours
4. Purge Liquid Temp Inhibit (Enable, Disable), Enable Enum
5. Purge Liquid Temp Limit XXX.X Temperature
Display Settings
Description
Resolution or (Enumerations), Default Units
1. Date Format (“mmm dd, yyy”, “dd-mmm-yyyy”), “mmm dd, yyy” Enum
2. Date
3. Time Format
(12-hour, 24-hour), 12-hour Enum
4. Time of Day
5. Keypad/Display Lockout
(Enable, Disable), Disable Enum
6. Display Units (SI, English), English Enum
7. Pressure Units (Gauge, Absolute), Absolute Enum
8. Language (English, Selection 2, Selection 3), English (2) Enum
(1) Temperatures will be adjustable to 0.1 degree F or C. The Main Processor provides the minimum and maximum allowable value.
(2) Adjustable to the nearest whole number percent. The Main Processor provides the minimum and maximum allowable value.
(3) Terminates with 10 minutes if inactivity
(4) The Date and Time setup screen formats deviate slightly from the standard screens defined above. See the time and date section for further details.
(5) Enables a DynaView
™ Lockout screen. All other screens timeout in 30 minutes to this screen when enabled. The DynaView ™ Lockout Screen displays a 0-9 keypad to
permit the user to exit the lockout with a fixed password (1-5-9 + Enter). See lockout setion for further details.
(6) Language choices are dependent on what has been setup in the Main Processor. Language selections will include English and qty 2 alternate as loaded by TechView ™ .
Language shall always be the last setting listed on the Display Settings menu. This will allow a user to find language selection if looking at an unrecognizable language.
(7) Manual Compressor Control allows an operator to override the Auto Control and manually control the compressor while in operation. This is not active during Stop
mode.
