Screw(stand+head) m4 x 14, Setting up the tv, Attaching the stand – LG 22LS3500-ZA User Manual
Page 5
A-3
SETTING UP THE TV
19/22/26LS35**
Model
19/22LS35**
26LS35**
Standard screw
P4 x 20
M4 x 14
Number of screw
2EA
2EA
32LS35**
SETTING UP THE TV
Attaching the stand
Image shown may differ from your TV.
1
2
Screw(Stand+Head)
M4 x 14
3
Screw(Stand+Head)
M4 x 14
M4 x 14
4EA
Stand Body
Stand Base
Screw(Stand+Head)
M4 x 14
Screw(Stand+Head)
M4 x 14
P4 x 16
4EA
1
3
2
Stand Body
Stand Base
