ASUS M11AA Desktop PC
15
EN
GL
IS
H
EN
GL
IS
H
Audio 2, 4, 6, or 8-channel configuration
Port
Headset
2�channel
4�channel
6�channel
8�channel
Light Blue
Line In
Line In
Line In
Line In
Lime
Line Out
Front Speaker Out
Front Speaker Out
Front Speaker Out
Pink
Mic In
Mic In
Mic In
Mic In
Orange
–
–
Center/Subwoofer
Center/Subwoofer
Black
–
Rear Speaker Out
Rear Speaker Out
Rear Speaker Out
Gray
–
–
–
Side Speaker Out
18. ASUS Graphics Card (on selected models only).
ASUS Graphics Card (on selected models only). The display output ports on this
optional ASUS Graphics Card may vary with different models.
19. ASUS WLAN Card (on selected models only).
ASUS WLAN Card (on selected models only). This optional WLAN card allows your
computer to connect to a wireless network.
20. Expansion slot bracket.
Expansion slot bracket. Remove the expansion slot bracket when installing an
expansion card.
Refer to the audio configuration table below for the function of the audio ports in a 2, 4, 6,
or 8-channel configuration.
