Multi-function compound interface, Av input wire a, Av input wire b – Myron&Davis NV7NAT1 User Manual
Page 9
7
Connected to iPod
iPod adapter (optional)
Multi-function compound interface
Left channel audio input
Video input
Red
V-IN
R-IN
L-IN
White
Camera/radar wire (Accessory of camera/radar)
AV input wire A
(optional)
Connected to radar
Connected to camera
Connected to camera
V-IN
Right
channel audio input
Video input
Right
channel audio input
Left channel audio input
Yellow
Yellow
(Male radar)
(Female lens)
(Optional)
Video input
AV input wire B
(optional)
Connect to steering
wheel control interface
(optional)
