Step 5: Reverse Door, if Desired
The door on this dryer is completely reversible. To
reverse door proceed as follows:
1. Remove four hinge attaching screws.
Figure 16
2. Remove all nine screws.
Figure 17
3. Pull bottom of door liner out, then pull down,
removing door liner from door panel.
Figure 18
4. Rotate door panel 180 degrees as shown.
Figure 19
5. Remove door strike from door liner and reinstall
on opposite side.
Figure 20
6. Insert liner under flange on bottom of door, then
push top of door liner into place.
Figure 21
7. Reinstall nine screws removed in Step 2.
Figure 22
8. Using screwdriver, remove two door plugs, and
reinstall on opposite side of door opening.
Figure 23
D675I
D675I
D272P
DRY1916N
B
A
DRY1916N
D273P
DRY1917N
DRY1917N
DRY1918N
B
A
DRY1918N
DRY1919N
DRY1919N
D620I D620I
