Page 25: 1 rating plate

8.4 Assembly

min.
50mm

min.
500mm

R 5mm

min.

55mm

560

490

min.
28 mm

min.
12 mm

min.
20 mm

8.5 Protection box

If you use a protection box (an additional

accessory), the protective floor directly

below the hob is not necessary. The

protection box accessory may not be

available in some countries. Please

contact your local supplier.

You can not use the protection

box if you install the hob above

an oven.

9. TECHNICAL INFORMATION

9.1 Rating plate

Modell EHF6241XOK

PNC 949 596 099 01

Typ 58 HAD 03 AO

220 - 240 V 50 - 60 Hz
Made in Germany

Ser.Nr. .................

6.4 kW

ELECTROLUX
