12. TECHNICAL SPECIFICATIONS:
Internal Dual Processing Dedicated 250 MHz High Speed Network Processor Ip3023
Dedicated High Speed Multi-Port Gigabit Switch & Co-Processor SparX-5
Hardware Interfaces 5 x 10/100/1000 Auto-Sensing Gigabit Ethernet LAN Ports MDI/MDI-X
1 x 10/100 Auto-Sensing Fast Ethernet WAN Port MDI/MDI-X
4 x Universal Serial Bus Connections (USB 1.1)
Standard IEEE 802.3 Ethernet Standard 10Mbps
IEEE 802.3u Ethernet Standard 100Mbps
IEEE 802.3ab Ethernet Standard 1Gbps
Certifications FCC Part 15, 15.247 15.205, 15.209, IC RSS 139 & RSS 210
LED Indicators WAN, LAN (Link and Activity), Power, Router Disconnect
Advanced Firewall Features Network Address Translation (NAT) Up to 254 Addresses
Stateful Packet Inspection (SPI)
AlphaGAP Logical Disconnect (Automatic and Manual)
MAC Filtering (Exclusion and Inclusion)
Website Filtering
Scheduling
AlphaGAP Connection Scheduler (ACS)
Gaming and Port Control Feature
Special Applications and Port Trigger
Configurable DMZ Port
Software Features StreamEngine Technology
Router Disconnection Scheduler
Up to 256 Firewall Port Configurations
Access Control Policies (Parental Control)
Internal and External System Logging
Static and Dynamic Routing
Oversized NAT Table
Print Sharing Capability
Email Alerts
Device Management Internet Explorer v6 or Later, or other Java-enabled Browser and Telnet
Power Requirements DC Wall Adapter 5.8 Volts 2.4 Amps
Dimensions and Weight 280 x 120 x 40 mm 250 grams
Environmental Operation 32F to 130F (0C to 55C) Humidity 95% Maximum (Non-Condensing)
Mean Time Before Failure (MTBF) 35,000 Hours
Warranty Limited Life Time Warranty
®
