ARRI A4 - Manual (Page 5)

ARRI X40/25
2500/4000W
ARRI Original Accessories
Photometric Calculator
www.arri.com
> products > lighting > support
Rear Loader
The Studio 5000, Compact 2500 and
Compact 4000 can be supplied with
‘Rear Loader’ lamp change option.
ARRI Cyc & Flood spotlights
ARRI Cyc 1250 Single
For further models please see the ARRI Cyc & Flood brochure.
L2.88109.0 Theatre Pipe Clamp with 28mm Socket
L2.88118.0 Barrel Clamp with 28mm Socket
L2.76989.0 Swivelling C Clamp with 28mm Socket
L2.88136.0 Quick Action Junior Clamp with 28mm Socket
L2.76990.0 Safety Cable 4mm x 1m for Lampheads to 20kg
L2.80864.0 Safety Cable 5mm x 1m for Lampheads to 45kg
Colours: theatre grey
Veam Schaltbau TV
connector std. con.
Standard
Manual:
L1.82410.B L1.82410.F
MB Ready*: L1.82420.B L1.82420.F
Technical Data:
Size (mm):
760H x 590W x 312L
Weight (kg): 24
Lamp: HMI 2500/4000 W/SE
Base: G38
Fixing: 28mm Male
Light Output (lux):
Distance: 3m 5m 10m
Flood: 7000 2520 630 128°
Ø: 12.3m 20.5m 41m
Accessories:
4-leaf barndoor
L2.82717.0
UV-protective frosted glass
L2.82740.0
Reflector, black
L2.82403.A
Adapter for Choke Ballast 2.5kW Veam
L2.77440.0
Adapter for Choke Ballast 2.5kW Schalt. TV std.
L2.77449.0
Choke Ballasts 220-240V
Choke Ballast 2.5 DMX Veam
L2.75024.E
Choke Ballast 2.5 DMX Schalt. L2.75024.D
Choke Ballast 4kW DMX Veam L2.75870.E
Choke Ballast 4kW DMX Schalt. L2.75870.D
Electronic Ballasts
EB 2.5/4kW DMX Veam
180-250V L2.76641.0
EB 2.5/4kW DMX Veam 90-125/180-250V L2.76676.0
EB 2.5/4kW DMX Schalt. 180-250V L2.76643.0
EB 2.5/4kW DMX Schalt. 90-125/180-250V L2.76678.0
