Arri daylight compact, Colours – ARRI A4 User Manual
Page 4
Colours:
theatre grey
Veam
Schaltbau TV
connector std. con.
Standard
Manual:
L1.73680.B
L1.73680.F
MB Ready*:
L1.73690.B
L1.73690.F
Rear Loader
Manual:
L1.73680TB
L1.73680TF
MB Ready*:
L1.73690TB
L1.73690TF
Technical Data:
Size (mm):
749H x 605W x 370L
Weight (kg):
23
Lamp:
HMI 2500 W/SE, 115V
Base:
G38
Lens (mm):
250
Fixing:
28mm Male
Light Output (lux):
Distance:
5m
10m
15m
Spot:
68900
17225
7656
Ø:
0.6m
1.2m
1.8m
7°
Middle:
11400
2850
1267
Ø:
2.7m
5.4m
8.0m
30°
Flood:
5290
1323
588
Ø:
5.8m
11.5m
17.3m
60°
Accessories:
4-leaf barndoor, 344mm
L2.80950.0
8-leaf barndoor, 344mm
L2.80970.0
Diffuser Frame, 330mm
L2.80970.0
Accessory cassette, modification kit
L2.83097.0
Choke Ballasts 220-240V
Choke Ballast 2.5kW DMX Veam
L2.75024.E
Choke Ballast 2.5kW DMX Schalt.
L2.75024.D
Electronic Ballasts
EB 2.5kW DMX Veam
90-125/180-250V
L2.76636.0
EB 2.5kW DMX Schalt.
90-125/180-250V
L2.76638.0
Colours:
theatre grey
Veam
Schaltbau TV
connector std. con.
Standard
Manual:
L1.74010.B
L1.74010.F
MB Ready*:
L1.74020.B
L1.74020.F
Rear Loader
Manual:
L1.74010TB
L1.74010TF
MB Ready*:
L1.74020TB
L1.74020TF
Technical Data:
Size (mm):
834H x 656W x 466L
Weight (kg):
27
Lamp:
HMI 4000 W/SE, 200V
Base:
G38
Lens (mm):
300
Fixing:
28mm Male
Light Output (lux):
Distance:
5m
10m
15m
Spot:
69700
17425
7744
Ø:
0.6m
1.2m
1.8m
7°
Middle:
16500
4125
1833
Ø:
2.7m
5.4m
8.0m
30°
Flood:
6420
4125
713
Ø:
6.4m
12.7m
19.1m
65°
Accessories:
4-leaf barndoor, 413mm
L2.81200.0
8-leaf barndoor, 413mm
L2.81210.0
Diffuser Frame, 400mm
L2.81220.0
Accessory cassette, modification kit
L2.83187.0
Choke Ballasts 220-240V
Choke Ballast 4kW DMX Veam
L2.75870.E
Choke Ballast 4kW DMX Schalt.
L2.75870.D
Electronic Ballasts
EB 2.5/4kW DMX Veam
180-250V
L2.76641.0
EB 2.5/4kW DMX Veam
90-125/180-250V
L2.76676.0
EB 2.5/4kW DMX Schalt.
180-250V
L2.76643.0
EB 2.5/4kW DMX Schalt.
90-125/180-250V
L2.76678.0
Colours:
theatre grey
Manual:
L1.75710.B
Technical Data:
Size (mm):
806H x 672W x 616L
Weight (kg):
34
Lamp:
HMI 6000 W/SE, 125V
Base:
G38
Lens (mm):
420
Fixing:
28mm Male
Light Output (lux):
Distance:
10m
15m
20m
Spot:
37200
16533
9300
Ø:
1.2m
1.8m
2.4m
7°
Middle:
7780
3458
1945
Ø:
5.4m
8.0m
10.7m
30°
Flood:
3310
1471
828
Ø:
11.3m
17.0m
22.6m
59°
Accessories:
4-leaf barndoor, 510mm
L2.82150.0
Diffuser Frame, 495mm
L2.82155.0
Choke Ballasts 220-240V
Choke Ballast, DMX
L2.75880.E
Electronic Ballasts
EB 6kW
180-250V
L2.76193.0
EB 6/12 DMX
90-125/180-250V
L2.76182.0
ARRI Daylight Compact
2500W
ARRI Daylight Compact
4000W
ARRI Daylight Compact
6000W
