Electronic Surface Element Control System (ESEC) Error Code Descriptions

When a specifi c error condition occurs in the ESEC system a code will be displayed in the electronic control panel. The error codes are displayed as
“CO” in the left display followed by the code number in the right display. For each Error Code there is a listing of the likely cause or failure condition, as well as
suggested corrective actions to be taken. Always reset the power by disconnecting or turning off the power supply for 30 seconds to see if the failure condition will
clear. If the error code returns perform the steps one at a time in the order listed below to correct the specifi c failure condition. NOTE: If multiple changing error
codes are displayed check for disconnected wires or cables.

Tech Sheet Abbreviations and Terminology

EOC = Electronic Oven Control

ESEC = Electronic Surface Element Control

TST = Touch Sensor Technology (touch control glass panel)

UIB = User Interface Board

TSEC = Touch Sensor Electronic Control

RTD = Resistance Temperature Device. (Temp Probe or Temp Sensor)

VSC = Variable Speed Control

PS = Power Supply board (PS1 , PS2, etc.)

TCO = Thermal Cut Out also “Thermo Disc” or “Thermal Limiter”

Error
Code

Likely Cause or Failure
Condition

Suggested Corrective Action

Stuck key

1. Verify nothing is touching the membrane control panels. Disconnect Power, wait 30 seconds and repower. If fault
returns: 2.Check/reseat membrane tails between the membrane panel and EOC; 3. Replace EOC; 4. Replace mem-
brane panel.

Membrane panel connector
tail

1. Disconnect Power, wait 30 seconds and repower. If fault returns: 2.Check/reseat membrane tails between EOC and
the membrane panel; 3. Replace EOC; 4. Replace membrane control panel.

20/27

Communication failure be-
tween generator board and
EOC - left cooking zones

1. Verify communication harness between left and right side generator circuit board is not damaged and is properly in-
stalled; 2. Verify AC power harness is not damaged and is properly installed; 3. Verify ID1 jumper is properly installed;
4. Replace the EOC; 5. Replace the left side generator board.

21/28

Communication failure be-
tween generator board and
EOC - right cooking zones

Communication failure be-
tween both generator boards
and EOC

1. Verify AC power supply to the appliance is 240V; 2. Verify communication harness between the EOC and the left
side generator board is not damaged and is properly installed; 3. Replace the EOC; 4. Replace both communication
harnesses; 5. Replace the left side generator board.

30, 35

AC input too high
AC input too low

1. Verify AC power supply to the appliance is 240V; 2. Verify cables and connections on the left side generator circuit
board are not damaged and are properly installed; 3. Replace the left side generator circuit board.

31, 32,
34, 36,
37, 40

Internal generator error

1. Verify cables and connections on the left side of the generator circuit board are not damaged and are properly
installed; 2. Replace the left side generator circuit board.

Cooling fan blocked

1. Verify cables and connections on the left side generator circuit board are not damaged and are properly installed;
2. Verify there is nothing touching or interfering with the fan on the left side generator circuit board; 3. Replace the left
side generator circuit board.

Cooling fan not connected

1. Verify fan is properly connected; 2. Replace the left side generator circuit board.

Confi guration error

1. Replace the EOC; 2. Replace both generator circuit boards.

Induction sensor (coils)
defect

1. Verify if the left side inductor (coils) are connected properly (measure approx. 0 Ohm); 2. Replace left side genera-
tor circuit board if 0 Ohm, otherwise replace the inductor (coil).

42, 43

General pot detection
Pot detection sensor failure

1. Verify pans are the proper material (magnet sticks to bottom of pan); 2. Verify pan is in the proper condition (not
warped, rusty); 3. Verify the pan is the proper size and placed correctly on the cooking zone. 4. Replace left side
generator circuit board.

Generator circuit board tem-
perature warning

1. Ensure cooktop is not being used with a dry pan at a high temperature setting; 2. Verify that installation follows the
installation instructions, check ventilation; 3. Allow zone to cool before continuing to cook.

Generator circuit board tem-
perature alarm

1. Ensure cooktop is not being used with a dry pan at a high temperature setting; 2. Verify that installation follows the
installation instructions, check ventilation; 3. Replace left side generator circuit board.

51
52
55
56

LF temp sensor failure
LR temp sensor failure
RF temp sensor failure
RR temp sensor failure

1. Verify induction temperature sensor is properly connected (see wiring diagram); 2. Verify the inductor temperature
sensor is properly installed and not damaged (measure approx. 100K Ohm at room temperature); 3. Replace applica-
ble generator circuit board, left or right (see wiring diagram).

63
64
67
68

LF temp sensor too hot
LR temp sensor too hot
RF temp sensor too hot
RR temp sensor too hot

1. Ensure cooktop is not being used with a dry pan at a high temperature setting; 2. Verify the inductor temperature
sensor is properly installed and not damaged (measure approx. 100K Ohm at room temperature); 3. Replace applica-
ble generator circuit board, left or right (see wiring diagram).

70
75

AC input too high
AC input too low

1. Verify AC power supply to the appliance is 240V; 2. Verify cables and connections on right side generator circuit
board are not damaged and are properly installed; 3. Replace the right side generator circuit board.

Error
Code

Likely Cause or Failure
Condition

Suggested Corrective Action

71, 72,
74, 76,
77, 80

Internal generator error

1. Verify cables and connections on the right side generator circuit board are not damaged and are properly installed;
2. Replace the right side generator circuit board.

Cooling fan blocked

1. Verify cables and connections on the right side generator circuit board are not damaged and are properly installed;
2. Verify there is nothing touching or interfering with the fan on the right side generator circuit board; 3. Replace the
right side generator circuit board.

Cooling fan not connected

1. Verify fan is properly connected; 2. Replace the right side generator circuit board.

Induction sensor (coils)
defect

1. Verify if the right side inductor (coils) are connected properly (measure approx. 0 Ohm); 2. Replace right side generator
circuit board if 0 Ohm, otherwise replace the inductor (coil).

82
83

General pot detection
Pot detection sensor failure

Generator circuit board tem-
perature warning

1. Ensure cooktop is not being used with a dry pan at a high temperature setting; 2. Verify installation follows the
installation instructions, check ventilation; 3. Allow zone to cool before continuing to cook.

Generator circuit board tem-
perature alarm

1. Ensure cooktop is not being used with a dry pan at a high temperature setting; 2. Verify installation follows the
installation instructions, check ventilation; 3. Replace right side generator circuit board.

Additional Failure Conditions

Symptom or Failure

Control Display

Possible Cause or Con-
dition

Suggested Corrective Action

Pan does not heat up.

Normal operation

Pan too small for proper pan
detection and only works
with low power.

Use larger pan or this pan on a smaller cooking zone. Refer to owners guide for
proper pan selection.

Flashing power
level Display and
pan does not heat.

Pan not detected.

Check whether the pots or pans are suitable for induction. Refer to owners guide
for proper pan selection.

Induction surface unit not
correctly connected or
surface unit open.

Check the surface unit wire terminal connections. Ensure that they are properly
connected and tightened. Test continuity of element (should be less than 1 ohm).

Distance between surface
unit and glass ceramic too
large.

Check whether the surface unit is properly positioned and touching the glass cooktop
surface.

Individual buttons
cannot be used or
cannot always be
used.

None

Test cables and
connections.

2. Membrane

control

panel defective.

3. EOC

defective.

Follow instructions for proper use of controls.

Verify membrane tail connections between EOC and membrane panel. Replace
if defective or damaged.

Replace membrane control panel assembly.

4. Replace

EOC.

Cooking power too
low or shuts down
prematurely.

None

Fluids spilled or object lying
on control panel keypads.

Clean up spills or remove objects. Restart cooktop in normal manner.

Normal Operation

Ventilation slots obstructed.

Clear vent openings.

Unsuitable pots (bottom
bent).

Follow owner's guide for proper pan selection

Distance between surface
unit and glass ceramic too
large.

Check whether the surface unit is properly positioned and touching the glass cooktop
surface.

Fan does not start.

With two cook zones operating, verify that the fan runs at a slow speed. If
fans do not run, check for foreign objects or stuck fan motor.

Test continuity of motor windings. Replace motor if open.

Replace induction control assembly.

Steady "HE" in
display when cooking
zone is cold and
switched off.

"HE"

Temperature sensor defect.

Test surface unit RTD approx. 1K ohms at room temperature. Replace surface
unit if resistance is not correct.

Replace induction control assembly.

Cooktop does not
initialize/operate.

Blank
No display
No beep

EOC not powered.

Verify installation and harness connections to EOC.

Defective EOC.

Replace EOC.
