Asanté FriendlyNET GX5-424W/448W/2400W
User’s Manual
12
Ports 25–26 Gigabit Status LEDs
Link/Activity
On
The respective port is successfully connected to an Ethernet
network.
Blinking
The port is transmitting or receiving data on the Ethernet
network.
Off
No link.
100 Mbps
On
The respective port is connected to a 100 Mbps Fast Ethernet
network.
Off
The respective port is connected to a 10 Mbps Ethernet or 1000
Mbps Gigabit Ethernet network.
1000 Mbps
On
The respective port is connected to a 1000 Mbps Gigabit Ethernet
network.
Off
The respective port is connected to a 10 Mbps Ethernet or 100
Mbps Fast Ethernet network.
Ports 27–28 SFP Mini-GBIC Status LEDs
Link/Activity
On
The SFP Mini-GBIC module is installed and connected to a
network.
Blinking
The SFP Mini-GBIC module is receiving data on a network.
Off
No link.
1000 Mbps
On
The respective port is connected to a 1000 Mbps Gigabit Ethernet
network.
Off
The respective port is disconnected from the network.
