Alcatel-Lucent 7710 SR SONET/SDH CMAs
P H Y S I C A L S P E C I F I C A T I O N S
Dimensions
• Height: 4.83 cm (1.9 in.)
• Width: 9.78 cm (3.85 in.)
• Depth: 29.85 cm (11.75 in.)
• Weight: 0.408 kg (0.9 lbs)
Environmental
Specifications
• Operating temperature:
5 C to 40 C (41 F to 104 F)
• Relative humidity: 15% to 85%
(non-condensing)
• Altitude: 1,800 m (5,906 ft)
Regulatory Agency
Standards
• Safety: EN 60950-1; IEC 60950-1;
EN 60825-1& 2; UL 60950-1; CSA
60950-1; AS/NZS 60950-1
• EMC: EN300 386; EN55022:
EN55024; FCC Part15 Class A;
IC ICES-003 Class A; AS/NZS
CISPR22
• Telecom: ACTA TIA-968-A (USA);
IC CS-03 (Canada); AS/NZS
S016:2001 (Australia)
Regulatory Markings
• CE Mark (Europe); WEEE
(Europe); A-Tick (Australia)
Table 1. Alcatel-Lucent 7710 SR CMA Types and Port Densities
CMA TYPE
PART NUMBER
INTERFACE SPEED
PORTS PER CMA
CONNECTOR TYPE
PORTS PER ALCATEL-LUCENT 7710 SR
SR-C4
SR-C12
10/100Base-T
3HE01022AA
10/100 Mb/s
8
RJ-45
32
64
1 Gigabit Ethernet
3HE01023AA
1 Gb/s
1
SFP
4
8
Channelized DS1/E1
3HE01020AA
1.5 Mb/s / 2.0 Mb/s
8
RJ-48c
32
64
DS3/E3
3HE01021AA
45 Mb/s / 34 Mb/s
4
1.0/2.3 BNC
16
32
SONET/SDH 3HE02185AA
OC-3c/OC-12c/STM-1c/STM-4c
2
SFP
8
16
