POWER SOURCE
The transmitter and receiver are each operated by a 9V alkaline
battery. Before use, install a battery as shown. Make certain the
battery is fully seated in its compartment so the cover slides in place
easily. Battery life with alkaline batteries is approximately 8 hours of
operating time. The receiver also features an external jack for
connecting a 9V DC power supply (not included).
TRANSMITTER OPERATION
B) If there is a “dead spot” in a room, try a slight change of position or
try changing frequencies.
Each unit provides two selectable transmitting frequencies.
1) Switch the Frequency Selector Switch to the desired channel (A or
B).
2) Belt clip on the back of the unit clips the transmitter onto a belt or
the transmitter simply can be put into a pocket.
3) Plug the microphone into the Mike Input Jack.
4) The microphone can be clipped to a necktie or other clothing,
using the supplied clip.
5) Slide the power ON/OFF switch to the ON position (the LED
indicator light will light).
Ribbon for battery removal
9V DC battery
Battery compartment cover
OPERATION
