AmpliVox SW915 - Manual

650 Anthony Trail, Suite D, Northbrook, IL 60062 PHONE: (800) 267-5486 - FAX: (800) 267-5489 WWW.AMPLI.COM [email protected]
QUICK SET UP
GUIDE PRINTED ON
CONTROL PANEL
Rated power output 250W Dynamic, 132W RMS
Battery (2) 12 volt rechargeable, 7.2 AH,
User accessible and replaceable
AC power 110-220 Auto sensing, 50/60 Hz,
Phantom Power Input Powers Electret condenser mics
Wireless Range Up to 200 Feet
Frequency response: 40Hz to 20Khz
Sensitivity 96dB
Equalization (tone) Separate Bass and Treble
Line output: Buffered, 600 ohm, 1/4in.-phone (pre fader)
Sensitivity for rated output:
Balanced Microphone -58 dBV (1.25 mVrms
Balanced Line -15 dBV (175 mVrms)
Unbalanced line -20 dBV (100 mVrms)
Unbalanced input: Hi-Z, Neutrik combo 1/4in.
Balanced Input: Lo-Z, Neutrik combo XLR
Weight: 35 lbs.
Dimensions (HWD): 23in.H x 11.5in.W x 11in.D
Warranty 6 years Electronics; 1 year on remote, Mics,
Cassette Player, CD Payer, Digital Player and
Rechargeable Batteries.
SW915 Digital Audio Travel Partner
Standard Unit Includes: 1 UHF 16-channel internal wireless receiver with
choice of wireless mic & transmitter - CD/CDRW/MP3 disc player with pitch
control - Wired XLR Mic
SW915 ................................................................................................................ $2,628
Customized options for 5 available slots
(factory installed)
Built-In additional UHF Wireless Receiver with:
S9112 Lapel/Headset Mic .....................................................................................$ 280
S9122 Handheld Mic ..............................................................................................$ 280
S9127 Flesh Tone Mic ............................................................................................$ 399
S9150 Cassette Tape Recorder/Player (variable pitch) ........................................$ 438
S9160 Digital MP3 Player/Recorder with SD slot ...................................................$ 438
Portable PA
DIGITAL AUDIO TRAVEL PARTNER
SW915
D I G I T A L A U D I O T R A V E L
PA R T N E R
w i t h R e m o t e C o n t r o l
Updated 1.10.13
LED indicators on speaker side of unit for:
POWER ON – BATTERY STATUS -
REMOTE SENSOR - UHF WIRELESS STATUS
n Features: 250 Watts, Audience Size up to 7,500,
Room size up to 25,000 sq.ft.
n
Built-in Digital UHF 16 channel wireless receiver
with choice of lapel, handheld, flesh tone or headset
mic with transmitter
n Wired XLR mic
n Built-in Digital CD/CDR/CDRW/MP3 disc player with pitch control
n
Digital pre amp
n
USB standard-B input
n Two 6.5 in. NEO woofers and dynamic compression driver, SPL 136dB
n
3 Neutrik Combo XLR mic Inputs
n
Mute
n
Reverb / Echo
n Talk-over (Ducking) - Automatic reduction of music when mic is used
n
Voice/Music Button
n
AC Power cord and rechargeable batteries for up to 10 hours of run time
n
A specially tooled and molded plastic enclosure for exceptional durability
with tripod mount & retractable handle & wheels
n
Remote control
n
Weight 35 Ibs.
REMOTE CONTROL
Unique feature lets you adjust master and individual
volume controls, mixer, reverb/echo, mute and talk-over
functions, from any location in room up to 50 ft. as the unit
has sensors on three sides.
