Specifications
CN-E14.5-60mm T2.6 L S CN-E14.5-60mm T2.6 L SP
Lens Mount Canon EF PL
Focal Length 14.5 to 60 mm
Maximum T-stop T2.6 (f = 14.5 to 60)
Iris Blade 11 pieces
Coverage
Super 35mm
Image Circle /
H x V (1.78:1)
Φ27.5 mm /
24.0 x 13.5 mm
Angular Field of View
(H / V) at wide angle end
79.2 / 49.9 degrees
Angular Field of View
(H / V) at telephoto end
22.6 / 12.8 degrees
Coverage
EOS C300
Image Circle /
H x V (1.78:1)
Φ28.2 mm /
24.6 x 13.8 mm
Angular Field of View
(H / V) at wide angle end
80.6 / 50.9 degrees
Angular Field of View
(H / V) at telephoto end
23.2 / 13.1 degrees
Coverage
EOS C500
Image Circle /
H x V (19:1)
Φ29.6 mm /
26.2 x 13.8 mm
Angular Field of View
(H / V) at wide angle end
84.2 / 50.9 degrees
Angular Field of View
(H / V) at telephoto end
24.6 / 13.1 degrees
Minimum Object Distance (M.O.D.) 0.7 m / (from the image sensor)
Object Dimensions
at M.O.D.
Super 35mm
65.2 x 36.7 cm at wide angle end
15.0 x 8.4 cm at telephoto end
EOS C300
66.9 x 37.5 cm at wide angle end
15.4 x 8.6 cm at telephoto end
EOS C500
71.2 x 37.5 cm at wide angle end
16.4 x 8.6 cm at telephoto end
Focus Angular Rotation 300 degrees
Zoom Angular Rotation 160 degrees
Spur Gear Module 0.8 metric module
Front Diameter Φ136 mm
Length 326 mm 318 mm
Weight 4.5 kg
* A variety of professional camera accessories compatible with the Φ19 mm rod system can be
used with this lens.
* This lens is compatible with EOS cameras that have a Super 35mm or equivalent sensor, or
an APS-C image sensor. The lens is not compatible with cameras that have a 35-mm full-size
sensor or an APS-H sensor.
