33 Specifcations
Physical Specifications
Enclosure.
Length: 3 3/4 inch
Width: 3 1/4 inch
Height: 1 1/4 inch
Visual indicators.
Power: ON/OFF Ready indicator;
Solid Green = Power on
Off = Power off
WLAN: WLAN indicator light that indicates whether or not it has at
least one session up.
Solid Light Green = LAN Cable connection or WLAN association to an
Access Point
Off = Modem power off or WAN connection not present.
Flickering Green = Wireless or LAN port activity (either direction)
Connectors:
RJ-45: One for Ethernet LAN connection
Power: One power connector for wall mount 12VDC power adapter
Reset Button: Reset the unit and Reset to manufacturing default
Antenna: One detachable using an RP-SMA connector
Environmental Operating Range
Operating temperature: 0-55 degrees Celsius
Humidity: 5-98%, non-condensing
Power Requirements
Operating voltage: +5V DC +- 5% @ 2A max
Power Dissipation
Active (typical) 5V DC @ 1.2A
