AVS02 / AVS04_ Product Reference Card

2 / 4-Port VGA Video Splitter

Split an identical VGA signal (up to 210 ft.) to 2 / 4 outputs

• Split VGA signals into 2 / 4 outputs
• Amplify the VGA signal to transmit over distance of up to
210 ft. - that is 8 times farther than the support of a typical
video card
• High signal bandwidth of 350MHz to support high quality video
• Daisy chainable to increase monitor support
• Supports VGA, SVGA and Multi-Sync monitors
• Plug-n-Play, No driver needed
• Limited 5 Year Warranty

(1) x 6’ VGA (male to male) Cable (1.8m)
Plastic
(1) x Blue (Active), (1) x Orange (Power)
10% to 85%, non-condensing
5°C~40°C (41°F~104°F)
AC 9V 600mA
AC 9V, Normal Operation 200mA,
Idle 10mA
1920 x 1440
5% to 90%, non-condensing
-20°C~60°C (-4°F~140°F)
2-port: 2.875 in. (7.3 cm), 2.5 in.
(6.4 cm), .75 in. (1.9 cm)
4-port: 3.25 in. (8.3 cm), 2.5 in.
(6.4 cm), .75 in. (1.9 cm)
2-port: 2.8 oz. (0.08 kg)
4-port: 3.5 oz. (0.1 kg)

(1) x HDB-15 female (VGA)
(2) x HDB-15 female (VGA)

Cable
Housing
LED’s
Operating Humidity
Operating Temperature
Power Adapter
Power Consumption

Resolution
Storage Humidity
Storage Temperature
Unit Dimensions (L x W x H)

Unit Weight

Video Input Connector
Video Output Connectors

VGA

IN port to CPU

Features

Specifications

aluratek.com

• Computers and monitors with HDB15
VGA connector

Requirements

• 2 / 4-Port VGA Video Splitter
• VGA Cable (6 ft.)
• Power Adapter
• Quick Start Guide
• Warranty / Registration Card

Package Contents

VGA

OUT ports (x2) to monitors

Power adapter port

2-port model shown

B

A

A

B

C

C
