Section 2: Specifications
Item Description
Units FO-DP-XX-MM (Transmitter) FO-DP-XX-MM (Receiver)
Unit Description DisplayPort Fiber Optic Transmitter DisplayPort Fiber Optic Receiver
Video Bandwidth 10bit Deep Color / 60Hz
Supported Resolution &
Distance
Up to WQXGA 2560 x 1600 @ 65 meters ( 210 feet)
Optical Converter 4 ch 850 nm Multi-Mode VCSEL 4 ch GaAs PIN photo Diode
Connector Type 20 pin DisplayPort Plug (Male) 20 pin DisplayPort Plug (Female)
Fiber Type 50/125 µm Multi-mode glass fiber
Environmental
Operating Temperature
32˚ ~ 104˚F (0˚ to 40˚C)
Storage Temperature -4˚ ~ 140˚F (-20˚ ~ 60˚C)
Relative Humidity 20~90% RH (no condensation)
2.1 Electrical & Optical Specifications
2.1.1 Transmitter (Source) Module
Parameter Symbol Min Type Max Units
Power
Supply Voltage Vcc +5.0 V
Supply Current Icc 250 mA
Power Dissipation Po 1.25 W
Signal
Diff. P-to-P Input Level 1 VTX-DIFF-PP1 0.34 0.4 0.46 V
Diff. P-to-P Input Level 2 VTX-DIFF-PP2 0.51 0.6 0.68 V
Diff. P-to-P Input Level 3 VTX-DIFF-PP3 0.69 0.8 0.92 V
Diff. P-to-P Input Level 4 VTX-DIFF-PP4 1.02 1.2 1.38 V
TX DC Common Mode VTX-DC-CM 0 2.0 V
TX AC Common Mode VTX-AC-CM 20 mV
Transmitter (Source) module of Model DPM includes 4 channel VCSEL (Vertical Surface Emitting Laser Diode)
with 850 nm invisible laser radiation.
Transmitter (Source) module of DPM is Class 1 Laser Product.
