Avenview FO-DP-XX-MM - Manual (Page 10)

www.avenview.com 10
2.3.2 Optical Cable Info
Dimensions of DisplayPort Cable
Items Unit Specifications
DisplayPort Cable Make-up - Layer Stranding
Drain Wires (Size/Stranded) mm(AWG) -0.203/7 (24)
AL-Mylar Screen Shield - A helically
Cable Outer Diameter Mm 7.40 ± 0.20
Jacket Color - Black
Fiber Cable Characteristics
Item Spec Unit Condition
Storage Temperature -20 ~ 70 °C Spooled
Operational Test 0 ~ 50 °C -
Max. Tensile Load 245 N
Min. Radius Bend 25
mm
40
Crush Resistance 490 N/50mm
