CONTROLS AND REAR PANEL PARTS
For Model: NTW5205TQ0
(White)
W10159160
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 3948608 Bracket, Control
2 8577845 Switch,
Water Level
3 Hose, Water
Inlet (2)
8571377 Blue Coupler
8571378 Red Coupler
4 3400073 Screw, Ground
5 8578869 Timer
(Motor Not A
Service Part)
6 90767 Screw, 8/18 x 3/8
7 388326 Screw, 8−18 x 1.25
(Panel To Top)
8 8271365 Cap, End (L.H.)
9 W10089722 Panel, Console
10 8271359 Cap, End (R.H.)
11 3400818 Screw, Timer
Mounting
12 W10110045 Knob, Timer
13 W10110046 Dial, Timer
14 W10110047 Knob, Control
15 8536939 Clip, Knob
16 8318015 Panel, Rear
17 3351614 Screw, Ground
18 3952821 Strain Relief,
Power Cord
19 8578842 Cord, Power
20 9740848 Screw, 8−18 x 1/2
21 8568314 Strap, Console (2)
22 8577378 U−Bend,
Drain Hose
23 3347868 Cable Tie
24 W10122138 Drain Hose
Assembly (Includes
Items 28 & 32)
25 8541669 Bucket, Drain Hose
(Left Half)
26 8541658 Bucket, Drain Hose
(Right Half)
27 62863 Srew, 10−16 x 3/8
28 8541668 Clamp, Hose
29 8317496 Clamp, Hose
30 3363366 Clamp, Hose
31 3951449 Hose, Pump To Tub
(Includes Item 30)
32 8541667 Clamp, Hose
33 8519200 Support, Rear
Panel
34 3958089 Harness, Wiring
(For Detail See
Pages 9 & 10)
35 62747 Pad, Rear Panel
36 8055003 Clip, Harness
& Pressure Switch
37 8539874 Shield, Suds
38 8578340 Valve, Water Inlet
W/Bi−Metal
39 301958 Clamp, Hose
40 8317974 Hose, Vacuum
Break
41 370450 Clamp, Hose
42 387606 Break, Vacuum
43 8572717 Capacitor,
Motor Start
44 8318046 Clip, Capacitor
45 3976300 Washer, Water
Inlet Hose (4)
(1−1/16 x 5/8)
