Service Router DS1/E1 ATM
IMA CMA Feature Details
IMA options include:
• n x T1/E1 ATM IMA version 1.1
• 1 to 8 member links per bundle
High-availability options include:
• IMA bundle and state configuration
• Non-stop service (NSS) for IES
and VPRN
• NSS for VPLS and VPWS
Alcatel-Lucent 7710
Service Router (SR) Family
The Alcatel-Lucent Service Router
(SR) family includes the 7710 SR and
the 7750 SR. Both are purpose-built
IP multiservice edge routers, targeted
for service providers, cable multiservice
operators (MSOs) and enterprise
customers committed to delivering
a new wave of triple play, premium
business virtual private network
(VPN) and multimedia mobile services.
Deployed worldwide in over 190
customers, the Alcatel-Lucent SR
has become the platform of choice
for network transformations and
convergence of services over a single
IP/MPLS network.
Technical Specifications
Physical Specifications
Dimensions
• Height: 4.83 cm (1.9 in.)
• Width: 9.78 cm (3.85 in.)
• Depth: 29.85 cm (11.75 in.)
• Weight: 0.408 kg (0.9 lb)
Environmental Specifications
• Operating temperature: 0 C
to 40 C (32 F to 104 F)
• Relative humidity: 15% to 85%
(non-condensing)
• Altitude: 1,800 m (5,906 ft)
For locations requiring compact form
factor and high-density TDM aggre-
gations, such as smaller point of presence
sites (POPs), collocation sites and
mobile RANs, Alcatel-Lucent offers
the 7710 SR. By leveraging the same
software and hardware design philo-
sophy as the 7750 SR, the 7710 SR
delivers cross-platform consistencies
and packet efficiency to the outer
parameter of a carrier’s networks.
The Alcatel-Lucent 7710 SR is available
in two chassis sizes: 4-slot and 12-slot.
With slots designed to accept CMAs
and selective Media Dependent
Adapters (MDAs), the 7710 SR-c4 can
support up to four CMAs, and the 7710
SR-c12 up to eight CMAs. Each CMA
has a 1.5-Gb/s full-duplex connection
to the Control and Forwarding Module
(CFM). With cost-optimization built
into every CMA, operators can right-
size a 7710 SR for a very specific
deployment.
Features of the Alcatel-Lucent
SR OS
In addition to the highlighted ATM
IMA features, the 7710 SR supports the
full scope of the Alcatel-Lucent SR OS
feature set, including:
• Flexible, high-performance services:
¬ VPLS
¬ Border Gateway Protocol (BGP)/
Multiprotocol Label Switching
(MPLS) VPN (based on RFC 4364)
¬ Dedicated Internet access services
¬ Ethernet, Frame Relay and ATM
VPWS
• High-performance IP and
MPLS tunneling
• Rich MPLS multiservice transit
capabilities
• Flexible Fast Path technology,
providing packet processing
• Thousands of configurable ingress/
egress access control lists (ACLs)
• Scalable BGP, Open Shortest Path
First (OSPF) and Intermediate
System-to-Intermediate System
(IS-IS) routing with traffic-
engineering extensions
• Per-service hierarchical QoS (H-QoS)
• Granular, per-service accounting
and billing
• Extensive operations, administration
and maintenance (OAM) tools for
service-aware troubleshooting and
faster service activation
www.alcatel-lucent.com
Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other
trademarks are the property of their respective owners. The information presented is subject to change
without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.
© 2008 Alcatel-Lucent. All rights reserved. WLN2197071009 (01)
Regulatory Agency Standards
• Safety: EN 60950-1; IEC 60950-1;
EN 60825-1& 2; UL 60950-1; CSA
60950-1; AS/NZS 60950-1
• EMC: EN300 386; EN55022:
EN55024; FCC Part15 Class A;
• IC ICES-003 Class A; AS/NZS
CISPR22
• Telecom: ACTA TIA-968-A (USA);
IC CS-03 (Canada); AS/NZS
S016:2001 (Australia)
• Regulatory markings: CE Mark
(Europe); WEEE (Europe); A-Tick
(Australia)
PART NuMbER DESCRIPTION INTERFACE TyPE APPLICAbLE IN 7710 SR
3HE02186AA 8 Port RJ-48c √
DS1/E1 ATM
Table 1. Alcatel-Lucent 7710 SR CMA Compatibility Matrix
