aquatic Industries, Inc. 2
syMPhony
rePlaceMent Parts list
* to indicate color, replace “XX” with “Wh” for White, “bo” for bone, “bK” for black, “st” for sterling silver, “bi” for biscuit, “cl” for clear and “br”
for oil rubbed bronze.
descriPtion Part # color/Finish
1a. Suction Cover 8152HvSUCvRXX* Specify Color
1b. Suction Wall Fitting 8414FTg *****
1c. Suction Elbow 8412FTg *****
2a. On/Off Air Button 8115BUTTNXX* Specify Color
2b. Air Button Body 8115BODY *****
3a. Directional Jet 1058 White
3a. Directional Jet 1059 Bone
3a. Directional Jet 1060 Biscuit
3a. Directional Jet 1061 Black
3a. Directional Jet 1062 Sterling Silver
3a. Directional Jet 1063 Clear
3c&d. Jet Body with Wall Fitting 1056 White
3c&d. Jet Body with Wall Fitting 1057 Clear
4a. .80 HP Pump 8078MOTOR *****
5a. Safety Suction valve 8150BSAFETY *****
6a. Pump Base 4618BASE *****
7a. Jet Body 8025JETBDY *****
7b. Spinning Back Jet 8475ROTJETXX *****
7c. gasket 8025gASKET *****
7d. Elbow 8841FTg (right) *****
8840FTg (left)
8a. Air Check valve 8441FTg *****
9. Bolt-On grab Bar (option) 901806gRAB White
Bolt-On grab Bar 901807gRAB Biscuit
Bolt-On grab Bar 901240gRAB Chrome
Bolt-On grab Bar 901220gRAB Brass
Bolt-On grab Bar 901260gRAB Satin Nickel
Bolt-On grab Bar 901270gRAB Polished Nickel
Bolt-On grab Bar 901210gRAB gold
Bolt-On grab Bar 901805gRAB Oil Rubbed Bronze
11a. Lift and Turn Waste & Overflow (option) 93CPDWO Chrome
Lift and Turn Waste & Overflow 93PBDWO Brass
Lift and Turn Waste & Overflow 93SNDWO Satin Nickel
Lift and Turn Waste & Overflow 93PNDWO Polished Nickel
Lift and Turn Waste & Overflow 93PgDWO gold
Lift and Turn Waste & Overflow 93ORBDWO Oil Rubbed Bronze
12a. geberit Cable Drive Waste & Overflow (option) --- Specifiy Color
13a. Maint. Heater (Stainless Heat Tube) (option) 8095THEAT ---
13b. 2pc. Heater Split Nut --- ---
13c. gasket / O-Ring --- ---
13d. 1.5 in. x 1in. Tailpiece --- ---
13f. 1.5 in. Tailpiece 8417SPIgOT ---
