Regular Checks During Sampling
Care must be taken at all times not to exceed the analyzer’s operating
specifications. In particular ensure the following:
• Do not exceed the maximum temperature of the flue probe
• The analyzer internal temperature does not exceed normal
operating range
• DO NOT PLACE THE INSTRUMENT ON A HOT SURFACE
• The water trap is correctly attached at all times - Water condenses
in the probe line and can quickly fill the water trap when the
probe is moved - Take care and watch the water trap closely
• The particle filter is clean and does not become blocked
Normal Shutdown Sequence
WARNING!
Turning the pump off while the probe is in the flue will leave toxic
gases inside the analyzer. Once data has been printed or copied it is
advisable to purge the unit with fresh air as soon as possible. To do
this, with the probe removed from the flue, turn ON the pump. Always
allow the readings to return to zero (20.9 for O2) prior to shutting
the unit off. (C75 only: The meter will not switch off until the CO
reading is below 20 ppm)
WARNING!
The probe will be hot from flue gases.
Remove the probe from the flue and allow it to cool naturally. Do not
immerse the probe in water, as this will be drawn into the analyzer
and damage the pump and sensors. Once the probe is removed from
the flue and the readings have returned to ambient levels hold down
“ “ and switch off the analyzer.
The instrument will count down from 30 to switch off.
If you pressed “ “ by mistake, pressing “ | | “ will return you to
normal operation.
Moving Through the Menu
The options in the menu system are in the following sequence by
pressing the down arrow:
Note: The menu choices are selected using the text printed on the case
above the function keys. The three keys are “ “ increases,
“ “ decrease and “ “ enter.
Set Time
1. Press “ENTER”.
2. Use the up and down keys to select the correct time.
3. Press “ENTER” to move to the next digit.
Note: Time is displayed in military format, example 7:00 pm
is 19:00.
Date
1. Press “ENTER”.
2. Select desired format for the date display.
• MM-DD-YY for month-day-year
• YY-MM-DD for year-month-day
• DD-MM-YY for day-month-year
3. Press “ENTER”.
4. Use the up or down arrows to select the correct data.
5. Press “ENTER” to move to the next digit and then exit.
TOP LINE
1. Press “ENTER”.
2. Use the up or down arrows to display desired data.
3. Press “ENTER” to save and exit.
Note: This can also be changed by pressing the “ “ key
when in normal mode more than 4 seconds.
C F
1. Press “ENTER”.
2. Select degrees displayed in Fahrenheit or Centigrade using the
up or down keys.
3. Press “ENTER” to save and exit.
CONTRAST
1. Press “ENTER”.
2. Select a value between 02 and 254 for desired contrast using
the up or down keys.
Note: Lower values result in a darker display.
SET FUEL
1. Press “ENTER”.
2. Select desired fuel using the up or down keys.
• Choices are Natural Gas, Light Oil, Propane, Butane and
Liquefied Petroleum Gas
3. Press “ENTER” to save and exit.
LANGUAGE
1. Press “ENTER”.
2. Select the desired language using the up or down keys.
3. Press “ENTER” to save and exit.
Header
1. Press up or down and “ENTER” to select desired header.
2. 2 lines of up to 16 characters will appear on the printout.
Store
1. Log - saves a set of test results when “ENTER” is pressed.
2. DEL ALL - clears all the memory when “YES” and “ENTER”
are pressed. Note: “ENTER” must be pressed to exit
this mode.
3. View
• The test number appears on the top line
• Rotate the dial position to displays the stored values
• Press up or down to display different tests
• Use “ENTER” to exit this mode
O2 Reference
1. This can be set between 0 and 20% to reference your readings
to a specific oxygen value.
