EA003 OPTICAL TACHOMETER CALIBRATION ADAPTER
OPERATION MANUAL
Transmille Ltd. Page 7
The main screen comprises of a main reading display, range selection buttons and
function selection buttons.
Sampling is indicated on the main
display by
Functions : Current Measurement
The current measurement function provides five ranges to measure current:
100uA • 10uA • 1uA • 100nA • 10nA
Functions: Resistance Measurement
The resistance measurement function provides five ranges. On initial selection of
resistance, the program will indicate a voltage should be set and the range buttons will
display ‘No Volts’.
Selecting a test voltage using the voltage selection controls :
Select a voltage from the drop down list, or by entering a voltage using
the keyboard.
Valid voltages are from 20V to 1000V.
Once a voltage is selected the range buttons will display the resistance ranges, for
example :
