Base Mounting
Template
THIS WAY UP
117
189
Drill Here Drill Here
Drill Here Drill Here
134
➯
Wiring Instructions
Remove velcro to reveal socket terminal cover screws.
6mm
stripped 6mm
stripped
E Green/Yellow
25mm L Brown
25mm
N Blue
25mm
➱
