TPS401 Powerseal

Outdoor Power Enclosure

Mounting Template

THIS W

A

Y UP

180 mm

284 mm

Wiring Instructions

Socket terminals are found by removing

the panel on the base of the socket strip.

6 mm
Stripped

N
Blue
25 mm

L
Brown
25 mm

E
Green/Yellow
25 mm

Cable Clamp

6 mm
Stripped
