Takagi T-D2-IN/OS - Manual

T-D2-IN
STK 00
Dimension H20.3” x W13.8” x D8.5” Weight: 39 lbs
Hot/Cold/Gas Connection 3/4” NPT
Clearances Top: 12“ Bottom: 12” Front: 24” Back: 1" Sides: 2 “
500 Wald, Irvine, CA 92618 Tel: (949) 770-7171 Fax: (949) 385-4886
www.takagi.com
U PC
®
02-21-2012
GAS 5-1/4" (135mm)
Ø 4" (101 mm)
COLD 3-1/4" (84mm)
GAS 4-7/8" (124mm)
120V 1-3/8" (36mm)
HOT 5-1/4" (133mm)
1-7/8" (47mm)
20
-1
/4
" (
52
0m
m
)
21
-3
/8
" (
54
4m
m
)
1-3/8" (36mm)
1-3/4" (45mm) 1-3/4" (45mm)
10" (254mm)
13-3/4" (350mm)
4-3/8" (113mm)
1-
5/
8"
(4
3m
m
)
19
-3
/8
" (
49
3m
m
)
COLD 2-7/8" (71mm)
1" (26mm)
HOT 6-1/2" (164mm)
9-1/2" (241mm)
120VAC 3-7/8" (99mm)

Fully modulating, gas fired,

Horizontal or Vertical Installation

TK-BF01
tankless water heater

Power Vent Backflow preventor

Indoor and Direc Vent

Electric Ignition

TK-KPCT43
installation only

Flue 4" O.D. 3X4 DV Concentric Termination

Safety Features:

Category III / IV Stainless Steel

TK-TV10

Air-Fuel Ratio (AFR) sensor

Intake 3" O.D. Direct Vent Conversion Kit

Exhaust & Water Temperature
 
TK-KPWL4 and TK-KPWH4
Safety Control Wall Thimble Louver/Hood

Overheat Cutoff Fuse Termination

Internal Freeze-Protection System
 
TK-PC01

Manual reset high limit switch Pipe Cover

Easy-link up to 4 units without
multi unit controller

HRS 35 Copper on Heat Exchanger

Power Cord included

Temperature Remote Controller
included (TM-RE30)
ABS, PVC, Galvanized Steel,
Corrugated Stainless Steel or
Category III/IV Stainless Steel
(90°elbow = 5' equivalent length)
4" ; 50' Max Length, 5 elbows max
Accessories Venting & Combustion Features
