The complete menu of the OSD is shown in the table below. The Main Menu icon for each menu is shaded, and
the individual functions within the group follow:
OSD Menu and Function
Contrast and Brightness
Contrast Controls the display contrast
Brightness Controls the display brightness
Video Adjustment
Auto Adjust Automatically sets display image size, position, and fine adjustment.
Contrast and brightness are not adjusted.
Left/Right Controls horizontal position
Up/Down Controls vertical position
Horizontal Size Increases or decreases the horizontal size of the image
Fine Controls the vertical fine adjustment. May improve picture detail in emulation modes.
OSD Tool
OSD Left/Right Adjusts the default horizontal position of the OSD on the display
OSD Up/Down Adjusts the default vertical position of the OSD on the display
OSD Timeout Determines time (in seconds) that OSD waits before closing automatically after no
action has been performed
Factory Reset Recalls original factory settings of image parameters
OSD Language Selects the OSD menu language—English, French, German, Italian, Spanish,
Japanese, Traditional Chinese, Simplified Chinese
OSD Color Selects one of ten OSD color schemes
Color Adjustment Adjusts preset color temperature of the image. Available choices are 9300, 7500,
6500, and 5500° Kelvin (K). A User mode allows custom setup of each color
component of the image—Red, Green and Blue. Default setup for this parameter is
6500°K. Do not adjust color temperature unless you have a specific need to do so.
Audio Adjustment
Volume Adjusts the loudspeaker volume
Mute ON/OFF Mute ON turns off the audio function. Mute OFF restores the audio function
Auto DIM
Auto Dim Turns the Auto-Sensing Brightness Adjustment circuit ON or OFF
Dimming Range Menu shows sensed light level, and brightness setting as a percentage of full scale
(same setting as Brightness in Contrast and Brightness menu when Auto DIM is
OFF). With Auto DIM ON, brightness is now controlled by the light sensor located
at top center of the front bezel. See additional discussion of this feature further in
this section.
