10
Power Supply Voltages External DC supply, +12VDC
AC input 100-240VAC/50-60 Hz
Power Dissipation Operating 45 W max AC
30 W max DC
Sleep Mode <4 W
Off <2 W
Power Saving VESA DPMS compliant
Temperature Operating +0°C to +50°C
Storage - 30°C to +60°C
Humidity Operating 20% to 80% non-condensing
Storage 5% to 95% non-condensing
Altitude Operating 0 - +12000 ft (3658m)
Non-operating 0 - +40000 ft (12192m)
External Connections Power IEC320 Standard AC inlet
Audio Standard 3.5mm Stereo Jack
Video HD15(VGA)
DVI-D 24pin
Touch Interface Standard USB series “B” receptacle
(detachable USB cable)
Standard DB9 F Serial (ATM-173R only)
(detachable serial cable)
POS Options Magstripe Reader 3 Track Reader with Power and Error Indicator
Light
Customer Display 2 x 20 VFD Display with Dual Axis (tilt & swivel)
Movement
Additional features Power indicator for display, built in to power switch; Power switch state memory
Digital on-screen display (OSD); Hidden, software lockable controls
Direct access to contrast, audio mute, and video auto adjust functions (bypass OSD)
Auto-Sensing Brightness Adjustment
Rubber Wedge Sealed touchscreen
Removable base
Two 75 mm VESA mounts (On base and display chassis)
Top or bottom access to countertop mounting holes
Kensington lock connection on chassis
Broad range of vertical tilt (-5° to +90°)
Two built-in 4W baffled speakers; 3.5mm Headphone Jack for private listening;
5W+5W Audio Amplifier
Two Port USB Hub (ATM-17RM/RMD/RMO and RMDO models only)
