Specifications:
Pre set voltages
Minimum input voltage the unit will run at: 13 volts for 12v models (26v for 24v models)
Voltage the unit switches off and drops into sleep mode: below 12.8 v for at least 15 minutes
(25.6v for 24v models)
Power consumption on sleep mode: 5 ma
Max input voltage trip: 15.5V (31V for 24V models)
Max output voltage trip: 15.5V (31V for 24V models)
All voltages refer to a default temperature of 20 deg C. If the battery temperature sensor is
used, these voltages will vary with the battery temperature, as the Digital Mobile Charge
takes this into account.
Alternator temp disengage: 100 deg C
Reset Alternator: 80 deg C
Battery temp trip: 50 deg C
Heat sink trip: 70 deg C
Heat sink reset: 60 deg C
Low battery alarm: 12.5V (25v for 24v models)
Low battery regulation: 13V (26v for 24v models)
High battery voltage trip: 15.5V (31v for 24v models)
Max input current at: 12V = 45 amps
Amp meter +/- 10%
Voltmeter +/- 1%
