86333800 TRIAD THRUSTER FAN

Ducting

Switch off and unplug fan from its power source
before connecting ducting. Also unplug any cords
plugged into the auxiliary outlets on fan.

Arrêtez et débranchez le ventilateur de sa source
d'énergie avant de relier la canalisation. Débran-
chez également tous les cordons branchés aux
sorties auxiliaires sur le ventilateur.

Be aware that ducting will move as it inflates or has
air moving through it.

Prenez conscience que la canalisation se
déplacera alors qu'elle se gonflera ou alors que l'air
passera à travers.

Exhaust Ducting

NOTE: Vent plate is normally placed in closed
position when using ducting.

Place quick-ducting band over lay-flat duct
approximately 1 foot from end.

Slide ducting 3 or 4 inches over front exhaust
nozzle, make sure it is even all around.

Secure in place by sliding quick-ducting band
along ducting and over exhaust ducting flange.

Verify that ducting is sandwiched between fan
exhaust nozzle and quick-ducting band and even
all around making a good seal.

Position fan and ducting in desired orientation and
location.

Plug fan into power source.

Turn off any additional fans or equipment and plug
into fans onboard auxiliary outlets.

Switch fan on.

Observe ducting as air starts to flow through it,
ducting may move around.

10. Switch on other equipment plugged into the

auxiliary outlet.

AVERTISSEMENT:

Operations
