Prochem Blazer GT User Manual
Page 75
73
86317260 BLAZER GT
Solution Outlet
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86270330
6
FLATWASHER, 1/4
2
86188130
1
NIPPLE, 3/8M X 1/4M
3
86190180
1
PLG, 1/8 SOCHD BR
4
86180210
1
ELL, ST 3/8 BR
5
86180220
1
ELL, 3/8 BR
6
86180360
1
ELL, 1/8P X 1/4T BR
7
86180420
1
ELL, 1/8P X 1/4T 45 DEG
8
86180450
1
ELL, 3/8P X 1/2T 45 DEG. BR
9
86002450
1
COUPLER, 1/4 QD
10
86270770
3
NUT, 1/4-20 HEX
11
86273850
3
SCR, 1/4-20 X 2.00 HHCS SS
12
86010780
3
WASHER, 1/4 SPLIT LOCK PLTD
13
86311640
1
ASSY, SOLUTION MANIFOLD, 6.63
14
86312630
1
NIPPLE, 3/8 X 2 BR
15
86192240
1
SCRN, MESH W/O-RING, SOL MNFLD
INCLUDES 17-18
16
86195030
1
VALVE, CHECK
INCLUDES 19-25
17
86189260
1
O-RING
18
86192210
1
SCREEN, CHECK VALVE
19
86189230
1
O-RING
20
86192390
1
SEAT, CHK VLV ASSY
21
86194250
1
TEFLON SEAT
22
86190910
1
POPPET, CHK VLV ASSY
23
86193260
1
SPRING
24
86189270
1
O-RING, 7/8 ID 1-1/16 OD
25
86176350
1
CAP
