SMF2-FG Series Media Filter
Operating & Maintenance Manual
PEP Filters
• 322 Rolling Hill Road • Mooresville, NC 28117 • 800-243-4583 •
www.pepfilters.com
704-662-3133 (Outside USA) Page 13 of 16 Fax 704-662-3155
rev. 01/02
Table 1: Inspection Chart
Part
SMF-FG Model
Filter Tank
X
Valves & Linkage
X
Filter Inter-connecting Piping
X
Pump pre-strainer tank & basket
X
Pump
X
NEMA 4X Box (Automatic only)
X
Filter skid
X
Pressure gauge, air relief valves, & tees
X
Media (ship loose)
X
Table 2: Connection Sizes
System Water Backwash
City Water
Backwash
Filter
Model
Pump
Inlet
Filter
Outlet
Waste
Outlet
Inlet City
Water
SMF2-FG
in / mm
in / mm
in / mm
in / mm
20
2 / 50
2 / 50
2 / 50
2 / 50
24
2 / 50
2 / 50
2 / 50
2 / 50
30
2 / 50
2 / 50
2 / 50
2 / 50
36
2.5 / 63.5
3 / 76.2
3 / 76.2
3 / 76.2
42
3 / 76.2
3 / 76.2
3 / 76.2
3 / 76.2
48
3 / 76.2
3 / 76.2
3 / 76.2
3 / 76.2
