Audiovox FRS-3000PK - Manual (Page 3)

3
Model FRS-3000PK Mobile and Base Station
Transceivers
The mobile (hand-held) transceiver, when equipped with NiMH rechargable
batteries, can be recharged when placed in the fixed base station trans-
ceiver cradle, which also acts as a desk-top charger.
OUT OF RANGE
H
MON
SCAN
MODE
PTT
CHG
OUT OF RANGE
BASE STATION
RETRACTABLE
ANTENNA MOBILE
TRANSCEIVER
ANTENNA
MOBILE
(HAND-HELD)
RECHARGABLE
TRANSCEIVER FIXED BASE
STATION
TRANSCEIVER AC WALL ADAPTER
120 VAC TO 9 VDC
(P/N F30ADP)
WALL ADAPTER
OUTPUT PLUG
(9 VDC)
BASE STATION
INPUT JACK
(DC 9V)
