MadgeTech QuadTemp Data Logger - Manual (Page 9)

QuadTemp and OctTemp
Battery Life 18 months typical
Data Format Date and time stamped ºC, ºF, K, ºR, mV, V
Time Accuracy ±1 minute/month
Computer Interface USB (Interface cable required); 115,200 baud
Software XP SP3/Vista/Windows 7/Windows 8 (MadgeTech 4 only)
Operating Environment -20 ºC to +60 ºC, 0 %RH to 95 %RH non-condensing
Dimensions 7.24 in x 2.7 in x 1.02 in (183 mm x 68 mm x 26 mm)
Material Black anodized aluminum
Weight 15.2 oz (430 g)
Approvals CE
QuadTemp General Specifications Cont.
Battery Warning
BATTERY WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE, FORCE
OVER DISCHARGE, CRUSH, PENETRATE, OR INCINERATE. BATTERY MAY LEAK OR EXPLODE IF HEATED ABOVE
80 ºC (176 ºF).
Specifications subject to change.
See MadgeTech’s terms and conditions at www.madgetech.com
7
